· 产品介绍 /Products:
产品编号 Item number |
21447A |
21447B |
21447C |
产品型号 Model |
CC-50A | CPC-50A | HT-50A |
出 力 Crimping force |
100KN | 80KN | 70KN |
剪 切 范 围 Cutting range |
铜铝电缆CU/AL cable Φ50mm max |
钢丝绳steel rope cable Φ18mm max |
钢丝绳steel rope cable Φ15mm max |
钢芯铝绞线ACSR cable Φ50mm ma |
钢绞线steel strand Φ10mm max |
||
铠装电缆armored CU/AL cable Φ50mm max |
钢芯铝绞线ACSR cable Φ50mm max |
||
钢绞线steel
strand Φ16mm max |
铠装电缆armored CU/AL cable Φ50mm max |
||
行 程 Stroke |
50mm | 50mm | 40mm |
长 度 Length |
approx.620mm | approx.620mm | approx.660mm |
重量(KG) Weight |
approx.N.W6.1KG G.W9.1KG |
approx.N.W6.2KG G.W9.2KG |
approx.N.W6.5KG G.W8.9KG |
包 装 Package |
塑料箱plastic box | 塑料箱plastic box | 塑料箱plastic box |
